- M5 或 M4 额定载荷循环（2m/M5 或 1Am/M4 FEM/ISO），专为工业和制造应用而设计
- 带散热片和风扇叶轮的内置马达，可降低工作温度并减少拆卸时间
- 带可互换齿轮箱的模块化设计，可减少维护时间、零件和复杂性
- 极其轻便、紧凑的外形可实现快速、安全的安装和拆卸；移动应用的理想之选
- IP65 防护等级，内置排水管，提供防水和防尘保护；非常适合户外使用
- 新型定制链条型材，带有磷酸镁涂层，可抗腐蚀并延长使用寿命
- 3 级斜齿轮传动，可实现安静运行
- 持久润滑的封闭式齿轮箱
- 提供吊钩安装、吊耳安装、推/拉行走小车和马达驱动行走小车顶部悬挂
- 提供定制配置（ATEX 认证、食品级、并联、VFD、风力涡轮机定制等）
- 5:1 安全等级
- 提供 3 年保修
ELK 系列电动环链葫芦
新的 ELK 系列葫芦采用极其轻便的现代设计，具备出色的耐用性、模块化和灵活性。ELK 葫芦专为满足 A5/M5 载荷循环分类要求而设计，适用于严苛的工业级应用。ELK 已加入 Ingersoll Rand 的 CLK、MLK 和 HLK 高性能的葫芦系列。
<table>
<tr>
<td>Capacity (Metric Tons)</td>
<td>Capacity (lbs)</td>
<td>Base Model</td>
<td>Phase</td>
<td>Voltage</td>
<td>Speed</td>
<td>Speed (ft/min)</td>
<td>Speed (m/min)</td>
<td>Duty Rating HMI (FEM)</td>
<td>Power (HP)</td>
<td>Power (kW)</td>
<td>Falls</td>
<td>Headroom (In)</td>
<td>Headroom (mm)</td>
<td>Weight @ 10' Lift (lbs)</td>
<td>Weight @ 10' Lift (kg)</td>
<td>Chain Weight (lbs/ft)</td>
<td>Chain Weight (kg/m)</td>
</tr>
<tr>
<td>1/4t</td>
<td>550</td>
<td>ELK25-1NS25 1 ph</td>
<td>Single</td>
<td>115 / 230</td>
<td>Single</td>
<td>16</td>
<td>5</td>
<td>H4 (2m)</td>
<td>0.34</td>
<td>0.25</td>
<td>1</td>
<td>15.0"</td>
<td>381</td>
<td>37.5</td>
<td>17</td>
<td>0.23</td>
<td>0.34</td>
</tr>
<tr>
<td>1/4t</td>
<td>550</td>
<td>ELK50-1NS25 1 ph</td>
<td>Single</td>
<td>115 / 230</td>
<td>Single</td>
<td>32</td>
<td>9.6</td>
<td>H4 (2m)</td>
<td>0.74</td>
<td>0.55</td>
<td>1</td>
<td>19.2"</td>
<td>488</td>
<td>57.3</td>
<td>26</td>
<td>0.46</td>
<td>0.69</td>
</tr>
<tr>
<td>1/2t</td>
<td>1100</td>
<td>ELK50-1NS50 1 ph</td>
<td>Single</td>
<td>115 / 230</td>
<td>Single</td>
<td>16</td>
<td>5</td>
<td>H4 (2m)</td>
<td>0.74</td>
<td>0.55</td>
<td>1</td>
<td>19.2"</td>
<td>488</td>
<td>57.3</td>
<td>26</td>
<td>0.46</td>
<td>0.69</td>
</tr>
<tr>
<td>1t</td>
<td>2200</td>
<td>ELK50-2NS100 1 ph</td>
<td>Single</td>
<td>115 / 230</td>
<td>Single</td>
<td>8</td>
<td>2.5</td>
<td>H4 (2m)</td>
<td>0.74</td>
<td>0.55</td>
<td>2</td>
<td>20.8"</td>
<td>528</td>
<td>61.7</td>
<td>28</td>
<td>0.46</td>
<td>0.69</td>
</tr>
<tr>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
</tr>
<tr>
<td>1/8t</td>
<td>275</td>
<td>ELK25-1ND12</td>
<td>Three</td>
<td>230 / 460 / 575 / 380</td>
<td>Dual</td>
<td>32/8</td>
<td>9.6/2.5</td>
<td>H4 (3m)</td>
<td>0.50</td>
<td>0.37</td>
<td>1</td>
<td>15.0"</td>
<td>381</td>
<td>37.5</td>
<td>17</td>
<td>0.23</td>
<td>0.34</td>
</tr>
<tr>
<td>1/4t</td>
<td>550</td>
<td>ELK25-1ND25</td>
<td>Three</td>
<td>230 / 460 / 575 / 380</td>
<td>Dual</td>
<td>32/8</td>
<td>9.6/2.5</td>
<td>H4 (2m)</td>
<td>0.50</td>
<td>0.37</td>
<td>1</td>
<td>15.0"</td>
<td>381</td>
<td>37.5</td>
<td>17</td>
<td>0.23</td>
<td>0.34</td>
</tr>
<tr>
<td>1/4t</td>
<td>550</td>
<td>ELK50-1HD25</td>
<td>Three</td>
<td>230 / 460 / 575 / 380</td>
<td>Dual</td>
<td>63/16</td>
<td>19.5/5</td>
<td>H4 (2m)</td>
<td>1.00</td>
<td>0.72</td>
<td>1</td>
<td>19.2"</td>
<td>488</td>
<td>57.3</td>
<td>26</td>
<td>0.46</td>
<td>0.69</td>
</tr>
<tr>
<td>1/2t</td>
<td>1100</td>
<td>ELK50-1ND50</td>
<td>Three</td>
<td>230 / 460 / 575 / 380</td>
<td>Dual</td>
<td>32/8</td>
<td>9.6/2.5</td>
<td>H4 (2m)</td>
<td>1.00</td>
<td>0.72</td>
<td>1</td>
<td>19.2"</td>
<td>488</td>
<td>57.3</td>
<td>26</td>
<td>0.46</td>
<td>0.69</td>
</tr>
<tr>
<td>1t</td>
<td>2200</td>
<td>ELK50-2ND100</td>
<td>Three</td>
<td>230 / 460 / 575 / 380</td>
<td>Dual</td>
<td>16/4</td>
<td>5/1.3</td>
<td>H4 (2m)</td>
<td>1.00</td>
<td>0.72</td>
<td>2</td>
<td>20.8"</td>
<td>528</td>
<td>61.7</td>
<td>28</td>
<td>0.46</td>
<td>0.69</td>
</tr>
<tr>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
</tr>
<tr>
<td>1/2t</td>
<td>1100</td>
<td>ELK100-1HD50</td>
<td>Three</td>
<td>230/460/575/380</td>
<td>Dual</td>
<td>63/16</td>
<td>19.5/5</td>
<td>H4 (2m)</td>
<td>3.70</td>
<td>2.80</td>
<td>1</td>
<td>24.2"</td>
<td>617</td>
<td>136.6</td>
<td>62</td>
<td>0.92</td>
<td>1.37</td>
</tr>
<tr>
<td>1t</td>
<td>2200</td>
<td>ELK100-1ND100</td>
<td>Three</td>
<td>230/460/575/380</td>
<td>Dual</td>
<td>32/8</td>
<td>9.6/2.5</td>
<td>H4 (2m)</td>
<td>3.70</td>
<td>2.80</td>
<td>1</td>
<td>24.2"</td>
<td>617</td>
<td>136.6</td>
<td>62</td>
<td>0.92</td>
<td>1.37</td>
</tr>
<tr>
<td>2t</td>
<td>4400</td>
<td>ELK100-2ND200</td>
<td>Three</td>
<td>230/460/575/380</td>
<td>Dual</td>
<td>16/4</td>
<td>5/1.3</td>
<td>H4 (2m)</td>
<td>3.70</td>
<td>2.80</td>
<td>2</td>
<td>26.6"</td>
<td>676</td>
<td>145.5</td>
<td>66</td>
<td>0.92</td>
<td>1.37</td>
</tr>
<tr>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
<td>…</td>
</tr>
<tr>
<td>2t</td>
<td>4400</td>
<td>ELK200-1ND200</td>
<td>Three</td>
<td>230/460/380</td>
<td>Dual</td>
<td>32/8</td>
<td>9.6/2.4</td>
<td>H4 (1m)</td>
<td>6.00</td>
<td>4.50</td>
<td>1</td>
<td>27.1"</td>
<td>688</td>
<td>205</td>
<td>93</td>
<td>1.49</td>
<td>2.22</td>
</tr>
<tr>
<td>3t</td>
<td>6600</td>
<td>ELK200-2ND300</td>
<td>Three</td>
<td>230/460/380</td>
<td>Dual</td>
<td>16/4</td>
<td>4.8/1.2</td>
<td>H4 (2m)</td>
<td>6.00</td>
<td>4.50</td>
<td>2</td>
<td>29.8"</td>
<td>756</td>
<td>224</td>
<td>102</td>
<td>1.49</td>
<td>2.22</td>
</tr>
<tr>
<td>5t</td>
<td>11000</td>
<td>ELK250-2ND500</td>
<td>Three</td>
<td>230/460/380</td>
<td>Dual</td>
<td>16/4</td>
<td>4.8/1.2</td>
<td>H4 (2m)</td>
<td>6.00</td>
<td>4.50</td>
<td>2</td>
<td>34.4"</td>
<td>874</td>
<td>257</td>
<td>117</td>
<td>2.37</td>
<td>3.53</td>
</tr>
