第三代两用气动绞车

Model

Type

Rated Capacity at Top Layer kg (lb)

Lifting Speed at Top Layer m/min (fpm)

Air Consumption with Rated Load m3/min (ft3/min)

Air Volume Needed to Move Rated Load at Top Layer 3 m (10 ft)

Sound Level as per EN 14492-1 dB(A)

Drum Capacity(1) Rope Length m (ft)

Drum Capacity(1) Rope Diameter mm (in)

Net Weight kg (lb)

FA2BMR24MK1G

Personnel Lifting

920 (2,035)

62 (202)

10 (350)

0.5 (17.3)

87

392 (1287)

13 (1/2)

357 (786)

FA2.5AMR24MK1G

Personnel Lifting

1,420 (3,125)

58 (191)

20 (700)

1.0 (36.6)

87

392 (1287)

13 (1/2)

411 (905)

FA5AMR24MK1G

Personnel Lifting

2,280 (5,035)

41 (136)

20(700)

1.5 (51.5)

89

366 (1200)

20 (3/4)

837 (1842)

FA2BMR24MK1G

Utility Lifting

1,450 (3,200)

37 (122)

10 (350)

0.8 (28.7)

87

392 (1287)

13 (1/2)

357 (786)

FA2.5AMR24MK1G

Utility Lifting

1,860 (4,100)

43 (141)

20 (700)

1.4 (49.6)

87

392 (1287)

13 (1/2)

411 (905)

FA5AMR24MK1G

Utility Lifting

3,600 (8,000)

13 (43)

20 (700)

4.6 (162.8)

89

366 (1200)

20 (3/4)

837 (1842)
